Favor Tool - Spine workflow tutorial

January 4th, 2021

Choosing the right workflows allows you to create high quality animations in very little time. In our latest tutorial video Sinisa shows how to use Spine's Favor tool to work faster and smarter.

Join us on the Spine forum to discuss this video.

Rigging new poses - Spine workflow tutorial

December 24th, 2020

Creating poses with different art during your animations is a great way to expand the range of what your characters are able to do in Spine. We gave a glimpse of this in our mesh binding tutorial and have talked about it in several of our streams, the latest demonstrating a complete turnaround of Helmet the dog. In this blog post we'll summarize the steps to add and manage multiple poses in your Spine skeleton.

You can download the files to follow along here. We've included all required images, as well as a Spine project for each step.

Preparing the assets

Let's imagine that you have already rigged a character and you want to add a new pose in the middle of an animation. The first step is creating the additional assets required for the new pose. You can use Spine's PSD export to create a reference for your work for Photoshop or other image editing software. This is especially useful to create new assets for an animation, such as a torso with a different perspective. The PSD export gives you layers for all the attachments of an entire mid-animation pose, so you can more easily draw new attachments.

Once you are happy with your new assets, you can export them from your image editing software using these scripts. Below we assume you are using Photoshop and our corresponding PhotoshopToSpine script.

By using the [slot] tag and names in your Photoshop project that match the existing slots in your skeleton, Spine can automatically import your new assets in the correct place. For our festive Spineboy, we've created additional assets in the Photoshop project that you can find in the folder 2-spineboy-alt-images/ in the materials download accompanying this blog post.

Importing the assets

The PhotoshopToSpine script generates a JSON file along with images that you can import into your existing Spine project.

To import the new assets, open the Spine project you wish to import the new assets into (in our case that's 1-festive-spineboy.spine inside the folder 1-festive-spineboy-start/). Next, choose Import Data or drag and drop the JSON file on the Spine window to open the Import Data dialog (in our case that's the file festive-spineboy-alt-hands.json in the folder 2-spineboy-alt-images).

Uncheck New project to import the files into the current skeleton, then choose Import into an existing skeleton and Ignore the existing attachments to retain the meshes that already exist.

After clicking Import, Spine will place the imported attachments matching an existing slot under that slot. Attachments not matching any existing slot will be placed in new slots under the root bone.

Adding the new pose assets in Spine

We are now ready to integrate the new assets into the rig so that they can be used in animations.

The first problem is that the positions of the new attachments likely don't match the bones already present in the skeleton. You may be tempted to work around this problem by creating a new set of bones for the new poses. This can work fine, but has the drawback of crowding the skeleton with many bones, turning your character into an unmanageable octopus, and making it harder to navigate and use your rig in the long run.

How to rig the new pose images

There is a better approach to integrate new parts! We can store a pose inside an animation that will act as an alternative setup pose. This animation then also serves as a convenient source to quickly copy a pose and paste it into a new animation. Let's call an animation used for this purpose a "setup pose animation".

To get started, in setup mode, make the new attachments for the new pose visible, turn them all into meshes, and use Edit Mesh to create the mesh structures. Remember to follow the mesh creation tips and try to keep the vertex count low!

While still in setup mode, bind the new meshes to a bone that doesn't move in any animation, such as the root bone.

After you're done with the above steps, hide the meshes for the new pose, thereby restoring your original setup pose.

Tip: You can uncheck export in the animation properties so that this animation won't be exported. It will still be available in the editor for you to use.

Now it's time to create the "setup pose animation" for our new pose. Switch to animate mode and create an animation that will be used to store the new pose.

Tip: If the new pose of a limb is in perspective, you can translate the bones to bring them closer or farther away. You can move a child bone along the parent axis to make this procedure more exact. Try to match the rotation of the bones the best you can.

Show all the meshes that are required by the new pose. Since all the meshes are bound to the root, the bones that are the real parents of these attachments can be moved freely, without affecting the attachments. Match the bones to the new positions of the meshes.

Once you are satisfied with the bone positions in this animation, bind each mesh to the respective bones that should influence it and unbind the root bone.

To test the weights, it's best to create a new animation for testing. You can test them using the setup pose animation and then undo, but it's easy to forget and accidentally ruin the pose. Duplicate the setup pose animation and adjust the weights. Once you're satisfied with the results, the pose is ready to use!

Using the new pose


  • Press the spacebar to clear your selection. This will make all the dopesheet rows visible, making it easier to copy and paste in one click by selecting the keyframe from the first row.
  • Offset the keys that show the attachments so that they are in the middle of the animation to make the change less harsh.
  • Keep the images in separate slots and fade the new slots in if you'd like to create the illusion of a smoother transition with images that differ a bit more.

After setting everything up, making use of the pose is very easy: just copy all the keys from the setup pose animation to the new animation.

Adding new bones to be used in the new pose

As you add new parts to a pose, you may realize that you actually do need a new bone or two for better control. How can this be done when the pose is very different from the setup pose?

First, follow the procedure described in the last section to match the existing bones to the new meshes in the setup pose animation. Next, bind the meshes in the setup pose animation to the bone that will be the parent of the new bones, setting the weight to 100%.

Now switch to setup mode and make the new meshes visible. They may appear positioned strangely, but they are properly aligned with the bone that will be the parent of our new bones. Use the meshes as a reference to create the new bones. Once this is done you can hide the meshes again in the setup mode.

Switch to animate mode and in the setup pose animation bind the meshes to the newly created bones. Proceed by setting their weights in a test animation as described above.

Modifying a mesh in an alternative pose

What if the mesh structure can be improved and needs to be changed? This is easy in Spine version 4.0 and higher: you can simply use the Edit Mesh button in animate mode.

In earlier versions of Spine it's possible but a bit more difficult because Edit Mesh can only be used in setup mode. The mesh was bound for a pose in an animation and in setup mode it is likely distorted, making editing the mesh there difficult or impossible. It can be done, but it requires losing the mesh's weights. You can take note of the most important weight percentages or keep the vertices count low so that the weights are easier to recreate.

First weight all of the mesh vertices 100% to the root bone (or another bone that doesn't move). If you didn't unbind the root from the mesh, you can just set the weight to 100%, otherwise make sure to bind the root while in the setup pose animation so that the correct state of the mesh is stored when it is bound.

Go back to setup mode and activate the mesh, which now shows in its undistorted state in setup mode, then click Edit Mesh. Once your mesh modifications are complete, switch to animate mode, activate the setup pose animation and press update bindings to store the correct bone positions.

You can now edit the weights so that the mesh is influenced by the correct bones once again.


If you're more of a visual learner, we've got you covered! Erika has streamed these techniques on Twitch. Check out the complete stream or the digest version here:


This is a powerful technique to master as it unlocks a huge variety of expressiveness for your characters. For it to work it's important to be careful and pay attention to where you are binding the bones and that the setup pose animation is treated as carefully as in setup mode. Since this is an advanced technique, it is easy to get lost trying to remember all the steps, so we hope this blog post comes in handy for you.

Have you tried out this workflow? Let us know what you've created! We love to see your creations, so remember to tag them using #madewithspine on social media!

Stop by the Spine forum and let us know your thoughts about these techniques or ask questions if you get stuck.

Weight and Mass - Animating with Spine #1

December 6th, 2020

We are happy to announce the first video of our new "Animating with Spine" tutorial series where we'll teach you animation theory and how to apply those concepts in Spine. Whether you are new to Spine or looking to improve your skills, you will find many valuable tips!

This first episode is about understanding the properties of the objects being animated. Try to follow along and do the exercises yourself using the video's project files. The exercises are short and fun, but there is a lot to be learned. As we dive deeper into animating, everything else will be built on top of these basic concepts.

Stop by the Spine forum to discuss this post. Happy animating!

Spine v4-beta: it has a curve editor!

October 10th, 2020

We are happy to announce that the Spine v4-beta has begun! This is our largest release yet and brings many exciting changes. Spine v4 is faster and prettier, but most importantly it now has a curve editor!

To try it, just download and install the latest Spine launcher from your Spine license page. With the fancy new launcher you can run the v4-beta versions or any older Spine version, from 1.7 to 3.8.

You can also try out the beta using the Spine Trial.

What's new?

Check out some highlights below or see the full changelog for more granular details.


The primary new feature in v4 is that the graph view has been completely redone to show values across the entire animation. The new graph is very powerful and makes it easy to control how the values in your animations change over time.

Please note that we are still working on many improvements to the graph. Among other things, we know there's no selection in the graph yet and we know it would be great to be able to key X and Y separately. Don't worry, these things and more will be added soon! Right now it is most important that we get the basic graph functionality into your hands.

We'll have proper documentation once the graph is finished but until then, here's a video that will quickly get you up to speed with using the graph:

If you'd rather read text instead of watching a video, click here.


Spine is now 64-bit on all platforms, ensuring access to all of your available RAM. Out of memory errors are a thing of the past, plus it runs faster.

High DPI

Spine now looks magnificent on high resolution displays! High resolution graphics are used when you set the interface scale > 100% (usually 200%). Click the image above to see it at full size.

Color management

Enabling color management will use your monitor's ICC profile to display correct colors, for example on fancy wide gamut displays.

Linear/gamma workflows

You can now choose for Spine to use either gamma or linear space for blending. This is important when your game uses linear blending, so what you see in Spine will match how it renders in your game.

New launcher

The v4 launcher is packed with improvements. You can now choose the version and language before the editor starts. It uses our new server/CDN infrastructure and chooses the best server for your location and connection, which means downloading updates is a lot faster. It also handles errors well, trying other servers if one has a problem. Plus it looks cool!


Besides the above, we've done a whole lot of smaller improvements, even more than are listed in the changelog. Spine v4 is more efficient, runs about twice as fast, and special attention has been given to the fine details that make using Spine a pleasure.

We will continue to add features and improve the Graph over the course of the beta. We hope you enjoy these new features and that you are as excited as we are to see Spine taking this big step in its evolution.

Discuss this post on the Spine forum.
